BLACKMAGIC UltraStudio 4K Extreme 3 Capture & Playback Card with Warranty | BDLKULSR4KEXTR3

BLACKMAGIC UltraStudio 4K Extreme 3 Capture & Playback Card with Warranty | BDLKULSR4KEXTR3

In Stock
Brand: BLACKMAGIC
Product Code: BLACKMAGIC UltraStudio 4K Extreme 3
Product viewed: 2292
Including VAT

AED12,999.00

2 reviews Write a review

Qty

Delivery within 2 working days

Description
Reviews (2)

· 40 Gbps Thunderbolt 3 & PCIe I/O

· Advanced 4K 60p RGB/Stereoscopic Ingest

· 12G-SDI, HDMI 2.0, Analog Connections

· 4-Ch XLR and 2-Ch AES/EBU Audio

· Reference, Timecode, RS-422 Ports

· 4:4:4 Sampling

· Real-Time H.265 Encoding

· LCD Preview Screen

· Wide Mac/Windows Software Compatibility

· 2 RU Form Factor; Dual Built-In PSUs

BLACKMAGIC UltraStudio 4K Extreme 3 Capture & Playback Card with Warranty | BDLKULSR4KEXTR3 is manufactured by BLACKMAGIC.

BLACKMAGIC UltraStudio 4K Extreme 3 Capture & Playback Card with Warranty | BDLKULSR4KEXTR3 at the best price in the United Arab Emirates.

BLACKMAGIC UltraStudio 4K Extreme 3 Capture & Playback Card with Warranty | BDLKULSR4KEXTR3 can be delivered to United Arab Emirates.

The product/item is Brand New with Warranty.

Specifications:

Operating Systems	Mac OS X 10.9 Mavericks / 10.10 Yosemite / 10.11 El Capitan or later / Windows 8.1 or Windows 10
SDI Video Input	2 x 12 Gbps and 2 x 6 Gbps SD/HD/2K/4K Supports single/dual/quad link 4:2:2/4:4:4 2D/3D switchable
SDI Video Loop	4 x reclocked SD/HD/2K/4K linked to corresponding inputs
SDI Video Output	2 x 12 Gbps and 2 x 6 Gbps SD/HD/2K/4K Supports single/dual/quad link 4:2:2/4:4:4 2D/3D switchable
SDI Video Repeated Output	2 x 12 Gbps and 2 x 6 Gbps SD/HD/2K/4K Supports single/dual/quad link 4:2:2/4:4:4 2D/3D switchable
Optical Fiber Input/Output	Upgradeable to optional 2 x 12 Gbps Optical Fiber
HDMI Video Input	HDMI 2.0 type A connector with support for 2160p60
HDMI Video Output	HDMI 2.0 type A connector with support for 2160p60
Analog Video Input	1 x Component YUV on 3 BNCs, 1 x Composite NTSC/PAL on 1 BNC
Analog Video Output	1 x Component YUV on 3 BNCs, 1 x Composite NTSC/PAL on 1 BNC
SDI Audio Input	16 channels embedded in SD/HD/2K/4K
SDI Audio Output	16 channels embedded in SD/HD/2K/4K
HDMI Audio Input	8 channels embedded in SD/HD/4K
HDMI Audio Output	8 channels embedded in SD/HD/4K
Analog Audio Input	4 channels of professional balanced analog audio via XLR connectors and 2 channels of consumer unbalanced via RCA connectors
Analog Audio Output	4 channels of professional balanced analog audio via XLR connectors
AES/EBU Audio Input	2 channels unbalanced with sample rate converter on BNC connector
AES/EBU Audio Output	2 channels unbalanced on BNC connector
Mic Input	1 x 48 V microphone input via XLR connector Phantom power switchable via software control
Timecode Input	1 x XLR input
Timecode Output	1 x XLR output
Sync Input	1 x Reference input Blackburst in SD or Tri-Sync in HD
Sync Output	1 x Reference loop output Blackburst in SD or Tri-Sync in HD
Device Control	2 x Sony compatible RS-422 deck control ports Serial ports TxRx direction reversible under software control
Computer Interface	Thunderbolt 3, PCI Express
Power	2 x built-in international AC power supply with IEC C14 inlet 120-240 VAC, 50-60 Hz
Dimensions	19 x 9.5 x 3.5 inch / 48.3 x 24.1 x 8.9 cm
Weight	8.6 lb (3.9 kg)
Warranty	1-Year
