D-Link NCB-C6UGRYR-305-24 CAT6 UTP 24AWG Solid Networking Cable 305 Meter

  • In Stock
  • Brand: D-LINK
  • Product Code: NCB-C6UGRYR-305-24
  • Product viewed: 3344
  • Including VAT
  • AED389.00



Delivery within 2 working days
  • D-Link solid CAT6 cables are the best twisted-pair cables in the market for transmitting data over local area Networks (LANs).
  • These cables exceed performance requirements specified by the TIA/EIA-568C.2 and IEC 60603-7-4 standards.
  • As streaming video and multimedia over LAN are gaining popularity, users demand faster data transmission and reduced waiting time.
  • D-Link cables are ideal for simple, cost-effective and high-speed transmission performance.
  • They support a higher signal-to-noise ratio, providing better reliability for current applications and higher data rates for future applications.
  • D-Link NCB-C6UGRYR-305-24 manufactured by D-LINK .
  • D-Link NCB-C6UGRYR-305-24 at the best price in the United Arab Emirates.
  • D-Link NCB-C6UGRYR-305-24 can be free delivered to United Arab Emirates.
  • The product/item is Brand New with Warranty.

General
Brand D-Link
Model NCB-C6UGRYR-305-24
Color Gray
Technical Spec
Certifications Verified compliant with TIA/EIA-568C.2 standards by ETL ; CUL listed ; RoHs
Specific Features 4 Pairs Unshielded Twisted Pair (UTP) Cable ; Conductor Metal - Solid Bare Copper with 24 AWG ; Color Code - Gray ; Jacket Material - PVC UL94V-0 ; PE Central Cross separator
Technical Details Mutual Capacitance - 5.6nF/100m nominal ; Characteristic Impedance - 100¬±15% ; Nominal Velocity of Propagation - 69% ; Conductor Resistance - < 9.38¬/100m ; Mutual Capacitance - < 5.6nF/100m ; Resistance Unbalance - 5% Max ; Capacitance Unbalance - 330pF/100m ; Delay Skew - < 45nS ; ; Conductor Diameter - 0.520mm Nominal ; Insulation Diameter - 0.940mm Nominal ; Insulation Material - HD-PE ; Cable Diameter - 5.7mm ; Bending Radius - < 4 X Cable Diameter at –20°C ± 1°C ; Pulling Force: 11.5Kg ; Temperature Range: -20° to +70°C
Product Warranty
Warranty 12 Months
