High
quality imaging with 2 MP resolution
·
Efficient
H.265+ compression technology
·
Clear
imaging against strong back light by DWDR technology
·
Water
and dust resistant (IP67)
·
Easy
installation with Power over Ethernet (PoE) technology
·
Up
to 30m IR distance
Specifications:
Brand |
HiLook |
Model |
IPC-T221H |
Color |
White |
Interface |
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet
port |
Lens |
Focal Length & FOV: 2.8 mm, horizontal FOV 112.1°,
vertical FOV 60.0°,
4 mm, horizontal FOV
90.2°, vertical FOV 48.6°, Lens Mount: M12 Focus: Fixed Aperture: F2.0 |
Camera |
Image Sensor: 1/2.7" Progressive Scan CMOS Min. Illumination: Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux
with IR Shutter Speed: 1/3 s to 1/100, 000 s Slow Shutter: Yes Wide Dynamic Range: Digital WDR Day & Night: IR cut filter Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0°
to 360° |
Image / Video |
Image Settings: Saturation, brightness, contrast, sharpness,
AGC, Day/Night Switch: Day, Night, Auto, Schedule Image Enhancement: BLC, 3D DNR Main Stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60
Hz: 30 fps (1920 × 1080, 1280 × 720) Sub-Stream: 50 Hz: 25 fps (640 × 480, 640 × 360) 60
Hz: 30 fps (640 × 480, 640 × 360) Video Compression: Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG Video Bit Rate: 32 Kbps to 8 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.264+: Main Stream supports H.265+: Main Stream supports Region of Interest (ROI): 1 fixed region for main stream |
General |
Linkage Method: Upload to FTP, notify surveillance center,
send email Camera Material: Metal & Plastic Camera Dimension: Ø110 mm × 93.2 mm (Ø4.3" × 3.7") Package Dimension: : 150 mm × 150 mm × 141 mm (5.9" ×
5.9" × 5.6") Camera Weight: Approx. 320 g (0.7 lb.) With Package Weight: Approx. 556 g (1.2 lb.) General Function: Anti-flicker, heartbeat, mirror, password
protection, Firmware Version: V5.5.120 Power Consumption and Current: 12 VDC, 0.4 A, max. 5 W PoE:
(802.3af, 36 V to 57 V), 0.2 A to 0.15 A, Power Supply: 12 VDC ± 25%
PoE: 802.3af, Class 3 Power Interface: Ø5.5 mm coaxial power plug |
