  • -13% Hikvision DS-3E0318P-E/M(B) 16 Port Fast Ethernet Unmanaged POE Switch | DS-3E0318P-E/M(B)

Hikvision DS-3E0318P-E/M(B) 16 Port Fast Ethernet Unmanaged POE Switch | DS-3E0318P-E/M(B)

  • In Stock
  • Brand: HIKVISION
  • Product Code: DS-3E0318P-E/M(B)
  • Product viewed: 1782
  • Including VAT
  • Special price:

    AED519.00

    Old price:

    AED599.00

    You save:

    13%



  • Intelligent PoE Management. When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
  • Up to 300 m Long Range PoE Transmission. The distance between IPCs and switch can reach maximum 300 meters.
  • 4/8-Core Adaptive Power Supply with Less Power Loss. 8-core power supply reduces the power loss on cables.
  • 6KV Surge Protection to Improve Reliability in Harsh Environment. The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
Delivery within 2 working days

Buy Hikvision DS-3E0318P-E/M(B) 16 Port Fast Ethernet Unmanaged POE Switch | DS-3E0318P-E/M(B). Hikvision Switch Best Price in Dubai, UAE at ctens.com and Fast Free delivery to Dubai, Abu Dhabi, Al Ain, Sharjah, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain, United Arab Emirates.

  • Intelligent PoE Management. When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
  • Up to 300 m Long Range PoE Transmission. The distance between IPCs and switch can reach maximum 300 meters.
  • 4/8-Core Adaptive Power Supply with Less Power Loss. 8-core power supply reduces the power loss on cables.
  • 6KV Surge Protection to Improve Reliability in Harsh Environment. The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.

Network Parameters

Ports : 16 × 10/100 Mbps PoE ports, 1 × gigabit RJ45 port, and 1 × gigabit fiber optical Port

Port Type : RJ45 port, full duplex, MDI/MDI-X adaptive

Working Mode : Standard mode (default); Extend mode

Standard : IEEE 802.3, IEEE 802.3u, IEEE 802.3x

Forwarding Mode : Store-and-forward switching

High Priority Ports : Ports 1 to 8

MAC Address Table : 4 K

Switching Capacity : 7.2 Gbps

Packet Forwarding Rate : 5.356 Mpps

Internal Cache : 2.75 Mbits

PoE Power Supply

PoE Standard : IEEE 802.3af, IEEE 802.3at

PoE Power Pin :

End-span: 1/2(-), 3/6(+)

Mid-span: 4/5(+), 7/8(-)

8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)

PoE Port : Ports 1 to 16

Max. Port Power : 30 W

PoE Power Budget : 130 W

Dialing Function

Long Range : Ports 9 to 16: up to 300 m; and the speed rate of the port is 10 Mbps.

General

Dimensions (W × H × D) : 266 mm × 44.5 mm × 220.8 mm (10.5” × 1.8” × 8.7”)

Shell : Metal material

Gross Weight : 2.58 kg (5.69 lb)

Net Weight : 1.80 kg (4.00 lb)

Operating Temperature : –10 °C to 55 °C (14 °F to 131 °F)

Operating Humidity : 5% to 95% (no condensation)

Storage Temperature : –40 °C to 85 °C (–40 °F to 185 °F)

Storage Humidity : 5% to 95% (no condensation)

Power Supply : 100 to 240 VAC, 50/60 Hz, Max. 2.5 A

Power Consumption In Idle : 20 W

Max. Power Consumption : 150 W

Approval

EMC

FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014,

EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015);

RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)

Safety

UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)

Chemistry

CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Buy Hikvision DS-3E0318P-E/M(B) 16 Port Fast Ethernet Unmanaged POE Switch | DS-3E0318P-E/M(B) Manufactured by Hikvision.

Hikvision DS-3E0318P-E/M(B) 16 Port Fast Ethernet Unmanaged POE Switch | DS-3E0318P-E/M(B)L best price at ctens.com in United Arab Emirates.

Hikvision DS-3E0318P-E/M(B) 16 Port Fast Ethernet Unmanaged POE Switch | DS-3E0318P-E/M(B) can be fast free delivered to Dubai, Abu Dhabi, Al Ain, Sharjah, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain, United Arab Emirates.

Hikvision DS-3E0318P-E/M(B) 16 Port Fast Ethernet Unmanaged POE Switch | DS-3E0318P-E/M(B) Best online price at ctens.com in UAE.
